22.00$
Ultra-compact Gigabit SFP Media Converter with AC to USB Adaptor and DC to USB Power Cord
1000 SFP port to 10/100/1000 RJ45 adaptive Gigabit Ethernet media converter. (Micro, mini, miniature, minimal, small size).
Introduction:
DS-MC-Micro is the ultra-compact plug-and play 10/100/1000Base-T to 1000Base-X media converter which is designed for applications where compact size, light weight and low power are critical requirements. It can be easily installed in tight places or conveniently slip into any pocket or laptop carrying case for easy portability with its ultra-compact size (79*23*18mm) and ultra-light weight (57 g).
This ultra-compact media converter can be USB powered by USB 1.0 or 2.0 port, which is ideal for connections to fiber in areas where a spare power outlet may not be available. When plugged into a computer’s USB port, the media converter shuts down automatically when you turn off the computer, which saves energy. So, this Ultra-compact media converter is an ideal solution for fiber-to-the-laptop where it needs Gigabit connectivity but local power isn’t available. For applications not utilizing USB power, this converter is also available with a 5V AC/DC power adapter, providing compatibility with electrical outlet types.
Features:
P/N | DS-MC-micro |
Port Interface | |
Fixed port | 1*1000 Base-X SFP, 1*10/100/1000 Base-T |
Power interface | DC jack (3.5*1.35mm) |
LED Indicators | |
Green LED | link/act indicator |
Yellow LED | 1000M link indicator |
Cable-type &Transmission Distance | |
Twisted-pair | 0-100m (CAT5e,CAT6) |
SFP slot | Depending on the SFP module |
Electrical & Layer 2 Specifications | |
Input voltage | DC 5V |
Total Power consumption | Full load≤1.2W |
MDX/MIDX | Support |
Jumbo Frame | Support 10Kbytes |
Watchdog | Support |
Environment | |
Operating temperature | -20℃~70℃ |
Storage temperature | -40℃~85℃ |
Relative humidity | 5%~95% (non-condensing) |
Thermal methods | Fan-less,natural cooling |
MTBF | 100,000 hours |
Protection & Certification | |
Surge protection of Ethernet port | IEC 61000-4-5 Level 3(2KV)(10/700us) |
ESD | IEC 61000-4-2 Level 4 (8K/15K) |
Free fall | 0.5m |
Certification | CE/FCC/RoHS |
Mechanical Dimensions | |
Product size | 79*23*18mm |
Installation Method | desktop |
Weight | 57g |
Ref. Packaging | 100pcs/ctn, Gross weight 16Kgs, ctn dim.57*48*30cm |
